3D fileXB-PM4510-CTX90U-F Specifications XT90
DrawingsXB-PM4510-CTX90U-F

▍Xibang material number：XB-PM4510-CTX90U-F

Product name:XT90 connector rated current:40A rated voltage:500V DC voltage:500V DC torque:35N~65N

Contact resistance:0.4MΩ Use temperature:-40°C±120°C Insulation resistance:2000MΩ Use life:5000次 Product code:ROHS

3D file and drawings

3D fileXB-PM4510-CTX90U-F Specifications XT90

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-PM4510-CTX90U-F 3D Drawings		21.8 * 10.7 * 20mm high-power 2P connector male female pair plug/model T-type interface XT90/new energy XT90 connector 45A/banana male female seat XT90/wiring terminal XT90 female seat/line end 2-core male female plug XT90/2P high current terminal XT90	XT connector	Normal	5 days/7 days	0.25g	1000	3000	100000	Yes	Consult

product material	1.XT90 connector	Material
	2.Hardware	gold plated brass
	3. Plastic shell	PA66
	4.Surface treatment	Gold plating (1μ~3μ)

Electrical properties	Rated current	40A
	Rated voltage	500V DC
	Insertion and extraction force	35N~65N
	Withstand voltage	500V DC
	Insulation resistance	2000MΩ
	Protection level	IP40
	Creepage distance	1.20mm
	Contact resistance (initial/after life)	0.4MΩ

Durability	No load life	5000 times
	Load life (maximum rated load)	5000 times
Environmental performance	Operating temperature	-20°C±120°C

Wiring recommendations:
AWG	Temperature rise 60°C	Temperature rise 85°C
8#	55A	60A
10#	50A	55A
12#	35A	45A
