3D fileXB-RJ45S-XKB08S Specifications XB-RJ45S-XKB08S-
DrawingsXB-RJ45S-XKB08S

▍Xibang material number：XB-RJ45S-XKB08S

插头类别

母座

操作方式

侧面操作

安装方式

插脚型

防水级别

防水

层数

单层

焊接方式

PCB板

离安装面高度

10mm

屏蔽

是

产品类别

RJ45

长度

37mm

产品证书

UL/CUL:E523734

3D file and drawings

3D fileXB-RJ45S-XKB08S Specifications XB-RJ45S-XKB08S-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-RJ45S-XKB08S 3D Drawings		Waterproof RJ45 connector base	8228	normal	6-8 weeks	19.000	210 pieces/box	0	10000	No competitive products	Consult

技术参数	适用温度:	-20℃ ~ +80℃
	胶芯材料:	PBT+GF
	端子材料:	磷青铜镀金
	螺丝/螺母材料:	FKM
	密封材料/密封圈:	FKM
	绝缘阻抗:	≥100MΩ
	接触阻抗:	≤30mΩ
	是否屏蔽:	是
	防护等级:	IP67紧锁状态

电气参数	芯数	8P8C pins
	额定电流	1.5A
	额定电压 A/C	125V
	额定电压D/C	125V
