3D fileXB-TS-LED-1215Y Specifications 带灯LED开关规格书
DrawingsXB-TS-LED-1215Y

▍Xibang material number：XB-TS-LED-1215Y-X

Product Name: LED Light Tact Switch Rated Current: 0.3A 0.5A Rated Voltage: 12V 30V LED: 12V Switch Function: Instantaneous

Operating force: 250gf ± 50gf Operating stroke: 0.25 ± 0.1 mm Service life: 100000 times Waterproof grade: IP50

Contact resistance: 30m Ω Insulation resistance: 100m Ω Operating temperature: -40 ℃~+85 ℃ Product certification: ROHS

3D file and drawings

3D fileXB-TS-LED-1215Y Specifications 带灯LED开关规格书

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-TS-LED-1215Y-X 3D Drawings		15 * 11.95mm light touch switch with light plug-in/circular light touch switch/button light switch/press light switch/LED light touch vertical switch/light switch DIP/light touch switch direct plug-in type		Normal	7-15 days	0.3g	1000	5000	1000	Nothing	Consult

Product type features	1. Light Tact Switch LED	material quality
	2. Lighting	LED lamp
	3. Button	PA66
	4. Shrapnel	SUS
	5. Plastic seat	PA66
	6. Card parts	H62-Y1

qualification
1. Operating temperature range:		-25℃±85℃
2. Rated value:		0.3A 30V DC LDE：12V DC
3. Insulation resistance:		100MΩ
4. Voltage resistance:		250V AC
5. Contact resistance:		30MΩ
6. Life:		100,000 times
7. Action force:		260±50gf

structural property	operating function:	Close (open)
	Configuration (extreme throw):	Unipolar-double throw
	Number of actuators:	1

Main character	Color (LED light):	Red / blue / yellow / green / white / purple / orange / double-color light

Contact features	Terminal substrate:	Brass silver plated
	Switch terminal plating material:	Silver plated / gold plated

machine accessory	Installation Type:	Through-hole / wire / plate
	Installation Angle:	Plug-in / patch

Shell properties	Process sealing	deny

Hand welding	welding temperature	Up to 350℃
	weld period	Up to 3s

Reflow welding heat test	test condition	function
		The body has no deformation, and can be satisfied with the mechanical and electrical performance
* Temperature refers to the temperature of the PC plate surface
* The PC plate is 1.0 mm thick
No lead tin test
Ingredients: tin 96.5% copper 3% silver 0.5%
Number of reflow welding: 1 time
