| Product Center > Switch > Photoelectric switch > Remote control signal receiving module > IRM-SMD series > IRM-H2xx series

Scan code to browse

3D fileXB-IRM-SMD-H2xxJ2 Specifications IRM
红外接收头頭应用手册_V1.2简中-1
DrawingsXB-IRM-SMD-H2xxJ2

▍Xibang material number：XB-IRM-SMD-H2xxTR2-X

Product type: Remote control signal receiving module Rated current: 5mA Rated voltage: 6V Lifetime test: 5000 times Installation method: Welding electroplating process: Brass silver plating Operating temperature: -25 ℃± 85 ℃ Product recognition Certificate: ROHS

3D file and drawings

3D fileXB-IRM-SMD-H2xxJ2 Specifications IRM
红外接收头頭应用手册_V1.2简中-1

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-IRM-SMD-H2xxTR2-X 3D Drawings		4.6 * 5.1 * 1.45mm infrared receiver head/remote control signal receiver head/infrared photoelectric device dot infrared receiver head/infrared receiver head anti-interference/remote control receiver head/induction remote control infrared head/infrared receiver/infrared receiver head/remote control receiver 4PIN	IRM-H2xx series	Normal	A week	0.36g	1000	3000	100000	Yes	Consult

product type	1.IRM-H2xx series

characteristic	• Suitable for various carrier frequencies
	• Suitable for continuous encoding
	• Low operating voltage and low power consumption
	• Optimized immunity to TFT backlight interference
	• High immunity to ambient light
	• Long reception range
	• High sensitivity
	• Lead-free and RoHS compliant

Application areas	• Set top box
	• television
	•AC
	• Sweeping robot
	• Audio and other AV equipment
	• multi-media equipment
	• Other devices using infrared remote controls
