product material
|
1. Toggle switch
|
Material
|
|
2.Plastic
|
PPA/PA10T/PA66
|
|
3.Contact sheet
|
brass
|
|
4.Button
|
POM
|
|
5. Pin
|
Brass silver plated/brass gold plated
|
|
6.Spring
|
SUS304
|
|
|
Electrical properties
|
Operating temperature range
|
-10℃±60℃
|
|
Maximum rating (resistive load)
|
6A 125V AC
|
|
Minimum rating (resistive load)
|
3A 250V AC
|
|
Operating force
|
450gf±150gf
|
|
Withstand voltage
|
500VAC
|
|
Insulation resistance
|
100MΩ
|
|
Contact resistance (initial/after life)
|
30MΩ
|
|
|
Durability
|
No load life
|
10000 times
|
|
Load life (maximum rated load)
|
10000 times
|
|
|
Environmental resistance
|
Cold resistance
|
-40±3°C/96h
|
|
Heat resistance
|
70±2°C/48h
|
|
Moisture resistance
|
40±2°90 to 95% relative humidity 96/h
|
|
|
Temperature alternating test
|
|
For example, in the environment shown in the icon, after 5 cycles, place it in a normal environment and test after 30 minutes.
|
No signs of damage to mechanical or electrical performance
|
|
|
Solderability test
|
|
More than 95% of the surface of the immersed part will be covered with tin
|
|
The top of the terminal is immersed in the solder pool 2mm deep, the temperature is 240±5°C, and the time is 3 seconds. Lead-free tin test: composition: tin 96.5%, copper 3%, silver 0.5%
|
|
Solder resistance test
|
When hand welding, the temperature needs to be controlled at 360±10℃ and the time is 3±0.5 seconds, but abnormal pressure cannot be applied to the terminals. Lead-free tin test: Ingredients: 96.5% tin, 3% copper, 0.5% silver
|
The body has no deformation and can meet the mechanical and electrical performance
|
|
|
0769-82056828
XB-T26-K2311-4P
3D
Drawings
