▍Xibang material number：XB-EN-06

Product Type: Encoder Rated Current: 0.1A 0.5A Rated Voltage: 12V 50V DC Withstand Voltage: 100V AC

Contact resistance: 30m Ω Insulation resistance: 100M Ω Life test: 10000 times Operating temperature -40 ℃± 85 ℃

Pressure: 10gf ± 5gf Stroke: 0.15 ± 0.05mm Installation Method: Welding/Welding Plate Product Compliance: ROHS

3D file and drawings

3D fileXB-EN-06 Specifications XB-EN-06-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-EN-06 3D Drawings		4.8 * 3.05 * 2.57mm incremental encoding switch/patch encoder/encoding switch SMD/mouse wheel switch/mouse encoding switch SMD/mouse switch SMD/mouse scroll switch 3PIN		Normal	5/7 days	0.42g	1000	3000	Normal	Yes	Consult

product name	1. Encoder	Material
	2. Contact spring	Copper alloy (C510)
	3. Shell	SPCC
	4. Anchor plate	SUS(301)
	5. Gear	PA66
	6. Base	PA66
	7. Terminals	Brass gold plated

	Operating temperature range	-30℃~85℃
	Rated current	0.1A 0.5A
	Rated voltage	12V 30V DC

Electrical properties	Withstand voltage	100V AC
	Insulation resistance	100MΩ min.
	Contact resistance (initial/after life)	30mΩ max.

Durability	No-load life	10000 times
	Load life	10000 times
