| Product Center > Socket > DC power Jack > DC socket vertical

Scan code to browse

3D fileXB-DC-F1360 Specifications XB-DC-F1360-
DrawingsXB-DC-F1360

▍Xibang material number：XB-DC-F1360

方向

垂直

安装方式

通孔

外孔

3.55mm

中心引脚

1.3mm

离安装面高度

6mm

额定电流

2.5A

外形尺寸

圆柱

额定电压

24V

防水级别

防水

屏蔽

否

产品证书

UL/CUL:E523734

3D file and drawings

3D fileXB-DC-F1360 Specifications XB-DC-F1360-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-DC-F1360 3D Drawings		35135 waterproof base 3.5x1.3x12.5	27318	normal	2-3 weeks	1.069	1000 pieces/bag	3000	10000	No competitive products	Consult

产品材质	Plastic:	Pbt black
	Waterproof tube	C3604 NI
	Terminal:	Brass NI
	Spring:	Phosphor bronze NI
	Silicone pad:

环境条件	Temperature range:	-20 °C/+70 °C

	Mating cycles:	≥ 5000
	Insertion force:	≤ 30 N *1
	Withdrawal force:	3–30 N *2

电气数据	Contact resistance:	≤ 30 mΩ
	Rated current:	2.5 A
	Rated voltage:	24 V DC
	Rated impulse voltage:	250 V/60 s
