3D fileXB-DC-3513FS-CB-SMT Specifications XB3.5
DrawingsXB-DC-3513FS-CB-SMT

▍Xibang material number：XB-DC-3513FS-CB-SMT-X

Product type: DC power Jack Rated current: 3A 5A Rated voltage: 12V 30V DC

Contact resistance: 30m Ω max Voltage resistance: 500 V AC MIN Insulation resistance: 100 M Ω min

Lifetime test: 5000 salt spray tests: 24 hours Installation method: solder board/wire

Insertion and extraction force: 2-30 N Pulling out force: 2-30 N Product certification: ROHS

3D file and drawings

3D fileXB-DC-3513FS-CB-SMT Specifications XB3.5

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-DC-3513FS-CB-SMT-X 3D Drawings		7.8 * 12.7 * 5.5mm waterproof DC socket/vertical plug-in DC socket/DC socket DIP/DC female seat/DC socket/DC connector IPX7/DC male seat 3513		Normal	4~7	0.35	1000PCS/box	10000	100000	Nothing	Consult

Product material	1. DC JACK	material quality
	2. The lid	PBT/PA66/POM
	3. Shrapnel	yellow metal
	4. The base	PBT/PA66/POM
	5. Touch	Brass / silver plated / gold plated
	6. Terminal	Brass / silver plated / gold plated

	Use the temperature range	-30°C±85°C
	Maximum rating (resistance load)	3A 30V
	Minimum rating (resistance load)	5A 12V

Electric performance	withstand voltage	500V AC
	insulation resistance	100mΩ max

lasting quality	No load life	5000 Times
	load life	5000 Times

Environmental resistance	Cold resistance	-40±3℃ for 96h
	resistance to effect of heat	80±2℃ for 96h
	Moisture resistance	40±2℃, 90 to 95%RH for 96h

1. Temperature change experiment	According to the figure below, after 5 cycles, the test was maintained under normal conditions for 30 minutes.
3. Temperature distribution
3. Temperature distribution
Hand welding	welding temperature	Maximum of 260°C
	preheating time	Maximum 60 seconds
	Continuous impregnation time	Maximum 3 seconds
	Welding times	1
