| Product Center > Socket > DC power Jack > DC socket patch

Scan code to browse

3D fileXB-DC-031A-SMT Specifications XB-DC-031A-SMT-
DrawingsXB-DC-031A-SMT

▍Xibang material number：XB-DC-031A-SMT

方向

水平

安装方式

表面安装

中心引脚

1mm

离安装面高度

5.1mm

屏蔽

否

额定电压

30V

额定电流

0.5A

外孔

3.8mm

外形尺寸

W11xD6.6xH5.1mm

产品证书

UL/CUL:E523734

3D file and drawings

3D fileXB-DC-031A-SMT Specifications XB-DC-031A-SMT-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-DC-031A-SMT 3D Drawings		DC connector patch W11.0xD6.6xH5.0, inner core 1.0	27424	normal	2-3 weeks	0.000	1000 pieces/bag	3000	10000	No competitive products	Consult

产品材质	contact foot:	bronze ag-plating
	sprinc:	bronze ag-plating
	pin:	bronze ag-plating
	housing:	pa9t

环境条件	Temperature range:	-20 °C/+70 °C

	Mating cycles:	≥ 5000
	Insertion force:	≤ 30 N *1
	Withdrawal force:	3–20 N *2

电气数据	Contact resistance:	≤ 100 mΩ
	Rated current:	12 A
	Rated voltage:	50 V DC
	Rated impulse voltage:	500 V/60 s
