| Product Center > Socket > DC power Jack > DC socket horizontal type

Scan code to browse

3D fileXB-DC-049A-SMT Specifications XB-DC-049A-SMT-
DrawingsXB-DC-049A-SMT

▍Xibang material number：XB-DC-049A-SMT

产品证书

UL/CUL:E523734

3D file and drawings

3D fileXB-DC-049A-SMT Specifications XB-DC-049A-SMT-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-DC-049A-SMT 3D Drawings		DC connector patch W12.5xD9xH6, inner core 2.0,2.5A 24V	28190	normal	1-2 weeks	0.000	500 pieces/bag	3000	10000	No competitive products	Consult

产品材质	hurve piece :	brass ag-plating
	sprinc:	bronze ag-plating
	pin:	bronze ag-plating
	housing:	pa66/pbt

环境条件	Temperature range:	-30 °C/+70 °C

	Mating cycles:	≥ 5000
	Insertion force:	≤ 30 N *1
	Withdrawal force:	3–20 N *2

电气数据	Contact resistance:	30 mΩ
	Rated current:	0.5 A
	Rated voltage:	30 V DC
	Rated impulse voltage:	500 V/60 s
