XB-DC-087| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-DC-087  3D
 Drawings |
 |
DC connector W12xD6.2xH4.4, inner core 1.65,2A 12V | 8157 | normal | 1 week | 0.000 | 500 pieces/bag | 2000 | 10000 | No competitive products |
| 产品材质 | Center pin: | Brass silver | ||
| Terminal 1: | Brass silver | |||
| Terminal 2: | Phosphor Bronze silver | |||
| Terminal 3: | Brass silver | |||
| Plastic: | Pbt | |||
| 环境条件 | Temperature range: | -20 °C/+70 °C | ||
| Mating cycles: | ≥ 5000 | |||
| Insertion force: | ≤ 30 N *1 | |||
| Withdrawal force: | 3–30 N *2 | |||
| 电气数据 | Contact resistance: | ≤ 30 mΩ | ||
| Rated current: | 2 A | |||
| Rated voltage: | 12 V DC | |||
| Rated impulse voltage: | 250 V/60 s | |||
