| Product Center > Socket > DC power Jack > DC socket horizontal type

Scan code to browse

3D fileXB-DC-0310-1.0= Specifications XB-DC-0310-1.0-
DrawingsXB-DC-0310-1.0=

▍Xibang material number：XB-DC-0310-1.0

Product type: DC socket Rated current: 1A 2A Rated voltage: 12V 30V DC

Contact resistance: 30m Ω max Voltage resistance: 500 V AC MIN Insulation resistance: 100 M Ω min

Life test: 5000 salt spray tests: 24 hours Installation method: horizontal

Insertion and extraction force: 2-30 N Extraction force: 2-30 N Product certification: ROHS

3D file and drawings

3D fileXB-DC-0310-1.0= Specifications XB-DC-0310-1.0-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-DC-0310-1.0 3D Drawings		DC socket 3510 DC female seat 90 degree center pin 1.0mm DC socket 1A 12V		Normal	3-5 days	0.3	500	5000			Consult

产品材质	Center pin:	Brass tin
	Terminal 1:	Brass tin
	Terminal 2:	Phosphor Bronze silver
	Terminal 3:	Brass tin
	Plastic:	Pbt
	Axis support:	Brass tin

环境条件	Temperature range:	-20 °C/+70 °C

	Mating cycles:	≥ 5000
	Insertion force:	≤ 30 N *1
	Withdrawal force:	3–30 N *2

电气数据	Contact resistance:	≤ 30 mΩ
	Rated current:	2 A
	Rated voltage:	12 V DC
	Rated impulse voltage:	250 V/60 s
