3D fileXB-DC-038 Specifications XB-DC-038-
DrawingsXB-DC-038

▍Xibang material number：XB-DC-038

方向

水平

安装方式

通孔

外孔

5.9mm

中心引脚

1mm

离安装面高度

11.5mm

外形尺寸

W12.5XD10XH11.5mm

额定电流

5A

额定电压

24V

屏蔽

否

产品证书

UL/CUL:E523734

3D file and drawings

3D fileXB-DC-038 Specifications XB-DC-038-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-DC-038 3D Drawings		DC connector W12.6xD11xH12.5, inner core 1.5,5A 24V large hole	8132	normal	1-2 weeks	1.574	500 pieces/bag	3000	10000	No competitive products	Consult

产品材质	Terminal 1:	Brass tin
	Terminal 2:	Brass tin
	Terminal 3:	Phosphor Bronze tin
	Plastic:	Pbt

环境条件	Temperature range:	-20 °C/+70 °C

	Mating cycles:	≥ 5000
	Insertion force:	≤ 30 N *1
	Withdrawal force:	3–30 N *2

电气数据	Contact resistance:	≤ 30 mΩ
	Rated current:	5 A
	Rated voltage:	24 V DC
	Rated impulse voltage:	250 V/60 s
