| Product Center > Socket > DC power Jack > DC socket horizontal type

Scan code to browse

3D fileXB-DC-042C-W-2.5 Specifications XB-DC-042C-W-2.5-
DrawingsXB-DC-042C-W-2.5

▍Xibang material number：XB-DC-042C-W-2.5

Product type: DC socket Rated current: 5A 7A Rated voltage: 12V 30V DC

Contact resistance: 30m Ω max Voltage resistance: 500 V AC MIN Insulation resistance: 100M Ω min

Life test: 5000 fog tests: 24 hours Installation method: Horizontal plug-in

Insertion and extraction force: 2-30 N Extraction force: 2-30 N Product certification: ROHS

3D file and drawings

3D fileXB-DC-042C-W-2.5 Specifications XB-DC-042C-W-2.5-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-DC-042C-W-2.5 3D Drawings		Horizontal DC socket high current 7A DC female seat horizontal 5525 high power DC socket high current DC connector 5521		Normal	3-5 days	0.5	500	50000	10000		Consult

产品材质	Center pin:	Brass tin
	Terminal 1:	Brass tin
	Terminal 2:	Sus tin
	Terminal 3:	Brass tin
	Plastic:	Pbt

环境条件	Temperature range:	-20 °C/+70 °C

	Mating cycles:	≥ 5000
	Insertion force:	≤ 30 N *1
	Withdrawal force:	3–30 N *2

电气数据	Contact resistance:	≤ 30 mΩ
	Rated current:	8 A
	Rated voltage:	24 V DC
	Rated impulse voltage:	250 V/60 s
