XB-DC-044B-5A-2.5-Xibang Electronics Co., Ltd. is a global OEM manufacturer that provides high-performance switch, socket connector components, solutions, and intelligent engines that connect the world!

| Product Center > Socket > DC power Jack > DC socket horizontal type

Scan code to browse

3D file Drawings

▍Xibang material number：XB-DC-044B-5A-2.5

产品类型：DC插座额定电流：2A 5A 额定电压:12V 30V DC

接触电阻:30mΩmax 耐电压:500 V AC MIN 绝缘电阻:1000 MΩ min

寿命测试:5000次盐雾测试:24小时安装方式：卧式

插拔力：2-30 N 拔出力：2-30 N 产品认证:ROHS

3D file and drawings

3D file

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-DC-044B-5A-2.5 3D Drawings											Consult

产品材质	housing:	high thermoplastic silver
	Terminal 2:	phosphor bronze silver
	Terminal 3:	brass silver
	Terminal 4:	Brass silver
	conter pin:	brass ni
	Terminal 6:	phosphor bronze ni
	cover:	sus

环境条件	Temperature range:	-20 °C/+70 °C

	Mating cycles:	≥ 5000
	Insertion force:	≤ 30 N *1
	Withdrawal force:	3–20 N *2

电气数据	Contact resistance:	≤ 30 mΩ
	Rated current:	5 A
	Rated voltage:	24 V DC
	Rated impulse voltage:	500 V/60 s
