XB-SW-3645H-45-QJ-2-Xibang Electronics Co., Ltd. is a global OEM manufacturer that provides high-performance switch, socket connector components, solutions, and intelligent engines that connect the world!

| Product Center > Switch > Tilt Sensor Switch > Ball type

Scan code to browse

3D fileXB-SW-3645H-45-QJ-2 (1) Specifications XB-SW-3645H-45-QJ-规格书
DrawingsXB-SW-3645H-45-QJ-2 (1)

▍Xibang material number：XB-SW-3645H-45-QJ-2

Product name: ball switch Rated current: 2uA-10mA Rated voltage: 1-6V Circuit function: inclined conduction

Contact resistance:>10 M Ω Closed circuit resistance:>10 M Ω Welding temperature: 260 ℃± 10 ℃, temperature resistance: - 40 ℃ to 85 ℃

Salt spray test: 95% RH, 40 ℃ for 24 hours Service life: 100000 cycles Product certification: ROHS

3D file and drawings

3D fileXB-SW-3645H-45-QJ-2 (1) Specifications XB-SW-3645H-45-QJ-规格书

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-SW-3645H-45-QJ-2 3D Drawings		This product is a ball type tilt sensor switch.		Normal	3~7 days	0.5	1000	5000	20000	No competitive products	Consult

产品材质	1.Ball switch	Temperature resistance nylon
	2.Ball	Strainless steel/Brass ,silver-plated
	3.Plastic cover	Temperature resistance nylon
	4. Pin	Brass ,silver-plated


	使用温度范围	Operating: -40℃ to 85℃
	最大额定(电阻负载)	10mA 6V DC
	最小额定(电阻负载)	2UA 1V DC

电性能	耐电压	500V AC for 1 minute
	绝缘电阻	>10 MΩ
	闭路电阻	<30 Ω


机械特性	端子拉力 Pull force of terminal	500gf for 1 minute
	盐雾测试 Salt mist test	95% RH, 40℃ for 24 hours
	操作寿命 Operating lifespan	200,000 cycles

焊接条件
波峰焊时	焊接温度	260℃±10℃
	焊接时间	<5秒



手焊接时	焊接温度	320℃±10℃
	焊接时间	2-3秒
