| Product Center > Socket > Audio Jack > 3.5 Audio socket DIP

Scan code to browse

3D fileXB-PJ-334-9P Specifications XB-P63200435-
DrawingsXB-PJ-334-9P

▍Xibang material number：XB-PJ-334-9P-X-X

Product name: Audio socket Rated current: 0.5A 1A Rated voltage: 12V 30V DC Contact resistance: 30m Ω max

Insulation resistance: 100 M Ω min, withstand voltage: 500V, insertion and extraction force: 3N-30N, extraction force: 3N-15N

Service life: 5000 times Operating temperature: -40~+85 ℃ Installation method: Plugin Product certificate: ROHS

3D file and drawings

3D fileXB-PJ-334-9P Specifications XB-P63200435-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-PJ-334-9P-X-X 3D Drawings		22.83 * 36.52 * 18.3mm 6.35 audio connector/microphone 6.35 headphone jack/plug-in microphone 6.35 headphone jack/6.35mm audio jack/audio 6.35 audio jack/6.35 headphone base horizontal plug/plug-in 6.35 audio jack/6.35MM audio jack vertical		Normal	1-2 weeks	0.000	1000 pieces/bag	50000	10000	No competitive products	Consult

产品材质	terminal 1:Audio socket	phosphor bronze,tin
	terminal 2:	brass
	terminal 3:	phosphor bronze,tin
	plastic:	pbt

环境条件	Temperature range:	-30 °C/+85 °C

	Mating cycles:	5000
	Insertion force:	2–20 N
	Withdrawal force:	2–20 N

电气数据	Contact resistance:	≥ 100 mΩ
	Rated current:	0.5 A
	Rated voltage:	30 V AC/DC
	Rated impulse voltage:	500 V/60 s
